Reduce secondary processing and increase fine adjustment structure,
which can process more accurate counterbore.
Processing steps for SAVANTEC sleeve type reverse scraper:
First, extend the Z-axis of the tool holder; Then easily insert the
cutterhead; Rotating the main tool holder of the cutterhead card;
Upward machining in a forward direction; Return and remove the
cutterhead; Exit the tool holder and complete the machining.
Characteristics of SAVANTEC sleeve type anti scraper:
Suitable for various machine tools: machining centers, boring and
milling machines, rocker drills, table drills, etc
The U-shaped disc is easy to install and fix without the need for
screws, saving time
The U-blade can be designed to be disposable.
Reverse Counterboring Tool is a special cutting tool mainly used
for machining reverse counterbore holes in existing holes. The
following is a detailed explanation of the Reverse Countering Tool:
Definition and purpose:
Reverse Counterboring Tool is a cutting tool used to machine
reverse, flat bottomed holes in existing holes. This tool is
particularly useful when specific shapes or depths of reverse
countersunk holes are required, and is commonly used in fields such
as mechanical manufacturing and mold manufacturing.
characteristic:
Reverse machining: Unlike traditional counterbore tools, the
Reverse Counterbore Tool cuts in the internal direction of the hole
during machining, forming a reverse counterbore.
Flat Bottom: Similar to conventional countersunk hole tools,
Reverse Counterboring Tool can also machine holes with flat bottoms
to accommodate the installation of fasteners or other components.
High precision: Due to the need for precise control of cutting
depth and shape, Reverse Counterboring Tool typically has high
machining accuracy.
Operation method:
Reverse Countering Tool is usually installed and used on equipment
such as drilling machines, milling machines, or CNC machine tools.
When operating, first use a regular drill bit to drill an initial
hole on the workpiece, and then replace it with the Reverse
Counterboring Tool to machine a reverse countersunk hole on the
basis of the initial hole.
Technical parameters (based on reference articles, but please note
that these parameters may vary depending on different brands and
models):
Diameter range: The diameter range of the Reverse Counterboring
Tool may cover different sizes from a few millimeters to tens of
millimeters.
Cutting depth: The cutting depth depends on the specific machining
requirements and workpiece material, but Reverse Counterboring Tool
can usually accurately control the cutting depth.
Material: Reverse Countering Tool is usually made of hard alloy or
other wear-resistant materials to ensure its high hardness and wear
resistance.
matters needing attention:
When using the Reverse Countering Tool, it is necessary to ensure
that the tool matches the workpiece material to avoid using
inappropriate tools that may result in poor machining results or
tool damage.
When operating, it is necessary to follow the safety operating
procedures of the machine tool to ensure the safety of personnel
and equipment.
Maintenance and upkeep:
Regularly clean and lubricate the Reverse Counterboring Tool to
maintain its good working condition.
If tool wear or damage is found, a new tool should be replaced in a
timely manner to ensure machining quality and efficiency.
Through the above explanation, I hope you have a clearer
understanding of Reverse Counterboring Tool.
